BSFSP-300 Automatic Facial Tissue Packing Machine

PRODUCT DETAILS

Main Features

* Adopting packing way by wrapping,folding and sealing with compact structure,it makes the packsge look beautiful and the seal tightened.
* Controlled by stepless speed regulation,touch screen and PLC,the display on the human-machine interface makes maintainance more simply.
* Applied with auto-arranging feeding conveyor with automatic production line,saving the labor cost to the maximum.
* It saves much packing material by means of photocell checking,servo tracking,and auto-stop of film feeding without product.
* High automation,high proffession,high efficiency and less trouble.
* With wide packing size range,various packing sizes can be quickly interchanged.
* The easy tear is made by pneumatic and roll cutting ways.It is applied with stepless speed motor and servo motor as the control system.

Applications
* Suitable for packing rectangular and square objects,such as non-highly tight tissue,square tissue,napkin,etc.

Main Tchnical Parameter

* Tissue sizes: (100~230)×(100~150)×(40~100)mm(L×W×H)
* Packing speed: 26~60 bags/min
* Air supply: 0.5~0.8MPa
* Machine weight: 3500kg
* Outer dimensions: 3560×5885×1925(mm)(L×W×H)
* Designed speed: 25~65 bags/min
* Heating power: 3.6kw
* Motor power:5.4kw
* Max packing size: 230×150×100(mm)(L×W×H)
* Working noise:<=78dB
* Packing film: CPP or any other laminated film.CPP
* Power supply type: 380V,50Hz
